Dc Earth Leakage Relay

These relays are ideal for detecting and localizing earth leakage in dc power systems. The dc leakage current is measured by electronic ag sensor inserted in each monitored load circuit. The measuring method is based on the principle that the positive and the negative current in a fault free load circuit sum to zero.
